Gigabyte Z790 Aorus Elite ax Ddr4 + Wifi

Gigabyte Z790 Aorus Elite ax Ddr4 + Wifi

all-in-one LGA1700 mb - with 16+1+2 phase digital VRM , hybrid core optimization , pre-mounted I/O shield with thermal armor + RGB Fusion 2.0 with on-board RGB display ( multi zones )

Addressable LED Strip Support

on-board buttons ( power + reset + clear CMOS + Q-flash )

2x copper PCBs design

MoSFET heatsinks with copper heatpipe

SmartFan6 with 6 temperature sensors + 6x hybrid fan headers

solid pin power connectors ( ATX 24+8+8pin )

PCIe armor with stainless steel shielding

2x thunderbolt card connectors

intel Z790 chipset

4x dual channel DDR4-5333(O.C)/3200 with XMP3.0 support upto 128Gb

6x SATA6G + 4x M.2/NGFF ( Gen4x4 ) with thermal guard 2 ( PCIe or SATA or Optane mode ) with raid 0/1/0+1/5/10

on-board display with HDMi+DP dual outputs ( depends on CPU )

Realtek ALC1220-VB 7.1 HD audio + optical s/pdif out

Realtek 8125 2.5Gb

intel Wifi-6E AX211 tri-band 2.4/5/6Gbps WiFi + bluetooth

3x PCi-Ex16 ( Gen5@16x + 2x Gen4@4x) for Quad-GPU CrossfireX (no SLi)

1x USB3 type-C ( Gen2x2 20GBPs ) + 2x USB3 type-A ( Gen2 10GBPs ) + 3x USB3 type-A ( Gen1 5GBPs ) + 4x USB2.0

atx
