Gigabyte X570S Aorus Master + Wifi

Gigabyte X570S Aorus Master + Wifi

AMD AM4 mb - with 14+2 phase digital VRM , pre-mounted I/O shield with thermal armor + RGB Fusion 2.0 with on-board RGB display ( multi zones )

Addressable LED Strip Support

on-board buttons ( power + reset + clear CMOS+ Q-Flash )

thermal backplate

2x copper PCBs design

MoSFET heatsinks with 4x DTH fins-array copper heatpipe

SmartFan6 with 9x temperature sensors + 10x hybrid fan headers

solid pin power connectors ( ATX 24+8+8pin )

4x memory armor with stainless steel shielding

3x PCIe armor with stainless steel shielding+double locking bracket

extra noise detection hardware monitoring

thunderbolt card connector

AMD X570s chipset

4x dual channel DDR4-5400(O.C)/3200

6x SATA6G + 4x Gen4x4 M.2/NGFF with 4x thermal guards ( PCIe or SATA ) with raid 0/1//0+1/5/10

on-board Realtek ALC1220-VB 7.1 Hi-Fi audio ( ESS ES9118 sabre DAC + TXC oscillator + gold plated audio jacks + optical s/pdif out )

intel i255 2.5 gigabit lan

intel WiFi 6E AX210 2.4/5Gbps dual band WiFi + bluetooth

3x pci-e 4.0 (16x+8x+4x) for Quad-GPU CrossfireX ( no SLi )

1x USB3 type-C ( Gen2x2 20GBPs ) + 5x USB3 type-A ( Gen2 10GBPs ) + 2x USB3 type-A ( Gen1 5GBPs ) + 4x USB2.0

atx
